RAPID INCINERATOR
|
can also reduce fluid substances to ashes
|
| The operating temperature of 950°C is attained within the space of a few minutes. The upper level, with 8 recesses each with a diameter of 34 mm, can take porcelain crucibles of up to 50 mm diameter for drying, pre-heating and fuming-off. Can also reduce fluid substances to ashes. The uninhibited exposure to oxygen speeds up the incineration process. The tilted position of the crucibles in the lower incineration bed (which has a length of 400 mm) allows excellent observation and access to the contents during the operation. Modern design, easy to operate, reliable, space-saving and of very good value. |
 |
Equipment:
The upper part and the housing are made of high-grade, stainless steel. There is a built-in 120 minute time-switch fitted with a buzzer signal to indicate when the desired time has been reached, the switch is permanently in the ON position.
The appliances have a safety switch which ensures that the power supply is automatically cut off when the service panel is opened. . All appliances are delivered ready-to-install with a 1,5 m cable and Schuko plug. |
| Type SVR/E with electronic temperature control (performance controller) |
| Type SV II, as above but without temperature control |
| complete, ready-to-install, heating element suitable for both models and all construction dates. (Order No. EH 400) |
| Order No. |
SVR/E |
SV II |
| Power |
2500 W |
| Voltage |
230 V |
| External Dimensions |
450 x 310 x 180 mm |
| Weight |
7 kg |
6 kg |
|
|
